Palmary · Mașini de rectificat cilindric
OCA-3265
High efficiency, high accuracy and maximum operational convenience angular wheelhead heavy duty type.
Specificații tehnice
- Swivel over table
- 320 mm
- Distance between centers
- 650 mm
- Max. external grinding diameter
- 300 mm
- Sarcină maximă
- 150 kgs
- Disc abraziv
- 610 x 150 x 203.2 mm
- Linear velocity
- 33 M/s
- Wheel head max. stroke
- 360 mm
- Table max. stroke
- 1200 mm
- Table swivel angle
- -1deg - 8deg
- Work spindle head swivel angle
- 0deg - +90deg
- Center taper
- M.T. No. 4
- Turație arbore
- 0-300 r.p.m.
- Sarcină maximă (Max. load of spindle)
- 35 kgs
- Wheel spindle motor
- 11 kW
- Table feed motor
- 1.8 kW (AC Servo Motor)
- Capacitate rezervor lichid de răcire
- 230 L
- Greutate utilaj
- 6800 kgs
