OCD-45150

Specificații tehnice

Swivel over table

450 mm

Distance between centers

1500 mm

Max. external grinding diameter

420 mm

Sarcină maximă

800 kgs

Disc abraziv

510 x 50-125 x 152.4 mm

Linear velocity

33 M/s

Wheel X axis auto. rapid advance

10 m/min

Wheel X axis max. stroke

350 mm

Wheel X axis min. setting unit

0.001 mm

Table Z axis auto. rapid advance

10 m/min

Table Z axis max. stroke

1970 mm

Table Z axis min. input increment

0.001 mm

Table swivel angle

-1deg-5deg

Work spindle head swivel angle

0deg (Fixed Type)

Center taper

M.T. No. 5 / M.T. No. 6 (opt.)

Turație arbore

0-210 r.p.m.

Tailstock center taper

M.T. No. 5

Tailstock type of motion

Hydraulic

Tailstock max. motion distance

60 mm

Wheel spindle motor

11 kW

Workhead spindle motor (AC Servo)

2.9 kW

Wheelhead feed motor (AC Servo)

2.8 kW

Table feed motor (AC Servo)

4.4 kW

Hydro-static hydraulic pump

0.37 kW (4P)

Wheel spindle lubrication pump

0.37 kW (4P)

Coolant pump

0.37 kW (2P)

Internal grinding spindle (opt.)

0.75 kW (2P)

Total voltage

30 KVA

Capacitate rezervor lichid de răcire

230 L

Greutate utilaj

12000 kgs
