PCB-6030

Specificații tehnice

Comandă numerică

FANUC

Standard grinding range

1-150 mm

Disc abraziv

610 x 305 x 304.8 mm

Linear velocity

45 M/s

Dressing device

Single-point / (opt.) Diamond roller

Regulating wheel size (O.D. x width x I.D.)

355 x 305 x 203.2 mm

Regulating wheel speed

10-200 r.p.m. (variable)

Regulating wheel tilt angle

+5deg--1deg

Regulating wheel swivel angle

+/-2deg

Dressing device swivel

+/-5deg

Dressing offset

0-20 mm

Disc abraziv (Grinding wheel motor)

30HP x 4P (22 kW)

Regulating wheel motor

5 kW servo motor

Coolant motor

1HP x 2P (0.75 kW)

G.W. lubrication

Oil mist type

R.W. lubrication

Oil grease type

Slide lubrication

Auto lubricator (LUBE)

Capacitate rezervor lichid de răcire

140 L

Spindle lubrication

1.0 L

Slide lubrication tank

4 L

Greutate utilaj

7000 kgs
