PSG-70100AHR

Specificații tehnice

Working surface of table

700 x 1000 mm (28" x 40")

Max. surface ground

700 x 1000 mm (28" x 40")

Max. distance center of spindle to table

600 mm (24")

Table speed

5-25 m/min (200"-1000"/min)

Table guideway

V & flat way

Auto. cross feed increment

0.5-20 mm (0.02"-0.8")

Rapid power cross feed

1100 mm/min (44"/min) 60Hz / 900 mm/min (36"/min) 50Hz

Rapid power head elevation (opt.)

300 mm/min (10"/min)

Auto. down feed (opt.)

0.001-0.999 mm/time

Disc abraziv

1750 r.p.m. (60 Hz) / 1450 r.p.m. (50 Hz)

Disc abraziv (Wheel dimension)

405 x 50 x 127 mm (16" x 2" x 5")

Putere motor arbore

10 HP / 15 HP (opt.)

Hydraulic pump motor

3 HP

Rapid head elevation motor

1 kW AC servo motor

Coolant pump

1/4 HP

Machine net weight

6600 kgs (15000 Lbs)

Machine floor space

4600 x 2550 mm
