Palmary · Mașini de rectificat verticale CNC

VIG-80

PALMARY vertical grinding machine with honeycomb type machine structure assuring the best possible rigidity and stability.

Palmary VIG-80 — Mașini de rectificat verticale CNC

Specificații tehnice

Comandă numerică: FANUC (with current gap control function)
O.D. grinding range: 65-800 mm
Max. I.D. grinding length: -225: 275 mm; 225-: 500 mm
Max. O.D. grinding length: 500 mm
Spindle swivel dia.: 850 mm
Max. workpiece length: 500 mm
Max. workpiece load: 1000 kgs
Distance spindle upper side to G.W.: 650 mm
G.W. diameter: 60-305 mm
Tool holder type: HSK-E100
Work table size (face plate): 850 mm
Work spindle speed: 15-150 r.p.m.
X axis traverse: 1330 mm
Z axis traverse: 700 mm
Disc abraziv: 22 kW
X axis motor: 7 kW
Z axis motor: 7 kW
ATC motor: 1.4 kW
Electricity: 42 KVA
Air (work pressure & discharge): 0.7 Mpa & 2400 NL/min
Capacitate rezervor lichid de răcire: 1200 L
Oil tank: 30 L / 25 L / 45 L
Greutate utilaj: 13000 kgs
